Creation of topographic maps for the territory of the field

Project's objective

Creation of digital topographic maps M 1: 25000 for the territory of the oil fields in accordance with the requirements of the current regulatory documents. The renewed TTC should solve the issues of subsoil use and mine surveying.

Work description

1. Collecting data about knowledge of the territory, elaboration of a method of work and regulatory documents.
2. Audit of the data of topographic and geodetic knowledge and source materials.
3. The quality and completeness of the available initial digital topographic maps of 1:25000 scale have been determined.
4. The procedure and technology of work on the creation of digital topographic maps has been determined with the preparation and approval by the Customer of the "Editorial and technical instructions for updating the DTМ", "Digital classifier of objects of a digital topographic map M 1: 25000" and "Rules for the digital description of objects of a digital topographic map M 1: 25000".

Results

The customer was delivered:

1. Digital topographic maps M 1:25 000 in the format "ArcGis" and "MapInfo" in SK-42, SK-95, MSKK95 in electronic form and on paper.
2. The provided products are grouped along the boundaries of the fields.
3. Technical report on the work performed: on paper and in electronic form
