Radar (SAR) imagery -  aerial and satellite surveying is one of the methods of remote sensing of the earth's surface, which makes it possible to obtain images of the terrain in the microwave range of the electromagnetic spectrum. Radar imaging provides images of the Earth's surface and objects located, regardless of weather conditions, in the daytime and at night, by emitting and receiving signals reflected from the earth's surface. Images or extracting information is the phase difference of the sent and reflected signal.

Radar imaging is a special kind of satellite or aerial images where microwave range is used to obtain information with wavelengths from 1 cm to 1 m.

Today Radar images, as rule as, it is SAR - synthetic aperture radar.

High-resolution images of the Earth's surface use LIDAR sensors.

The main advantages of radar satellite images are that you can get radar images regardless of the weather and time of day: microwave radiation freely passes through the clouds and does not require daylight, as images in the visible and IR ranges.

What do you need

Radar imaging is indispensable compared to other means of observation in difficult weather conditions. The ability to take pictures at any time of the day and in any weather, high accuracy in measuring the coordinates and geometric characteristics of objects. The ability to observe and detect objects invisible in optical or infrared ranges of the electromagnetic spectrum hidden by snow or vegetation cover, as well as those located under the surface of the Earth.

Modern Radar images are needed to maintain a land registry (cadaster); geological and topographic mapping; formation of digital terrain models (DTM) or digital surface model (DSM):

  • high-precision ones (with a spatial resolution of less than one meter and an accuracy of determining the height of about 0.3–2 meters);
  • 3D model cities and areas;
  • construction of digital maps of displacements of the Earth's surface, measurement of deformations of the reflecting surface with an accuracy of a wavelength.

Radar survey tasks

Initially, the tasks of radar survey were limited to studies of the ocean surface. Now the range of tasks of radar shooting has expanded, and radar shooting allows you to obtain data on millimeter displacements of objects on the earth's surface, track oil pollution and the ship's situation in the waters, as well as create digital terrain models (the well-known SRTM CMC is created on the basis of radar data processing).

Radar survey Processing

It is worth noting that the processing of the radar is quite a difficult task, because the radar image has an unusual image for the human eye in its raw form. Specialized software products are used for radar processing, and specialists should have the necessary experience in creating secondary products of radar space surveys. However, despite this, the advantages of radar make the use of radar shooting very popular.

Three degrees of radar data processing can be distinguished:

  • Complex Image (SLC) — information obtained by focusing the transmitter signal. The radar image at this level of radar processing includes two channels: an amplitude ("panchromatic") image in grayscale and an image of the signal phase, which is used to create digital terrain models and maps of the earth's surface displacements.

  • Geocoded snapshot. The radar image has a spatial reference in a certain coordinate system. Radar images at this level of radar processing are usually delivered in GeoTIFF format.

  • Orthotransformed image. High-quality radar image, without geometric distortion from the terrain. Radar satellite imagery at this level of radar processing is used to create cartographic materials and spatial analysis.
